Feature
To drive a brushless motor, you need a driver for driving. We offer low-cost drivers that can be driven directly from the battery. The battery cell has a variation of 15% to 20% when fully charged and discharged. In addition, since the actual voltage is set higher than the reference value, if the driver specification voltage is ± 10%, the normal driver needed a DC/DC converter. All of our drivers have a wide range of allowable voltage inputs and are capable of battery-powered operation.
| DC/DC not necessary | Because the drive voltage range is wide, it is possible to drive directly. |
|---|---|
| Quiet drive | In particular, Momotaro series is a sine-wave drive for silent sound. |
| Coreless Motor Compatible | Compatible with low impedance coreless motors. |
| Cored motor compatible | Model compatible with cored motor also available. |
| Compatible with censor-in model | |
| Low cost | Simple design made low cost possible. |
| Free rental | For the customers who purchase our motor, we are carrying out free rental for a certain period. |
Series
There are the Momotaro series of sine wave driving and the Venus series which pursued a low price. In addition, the AC servo driver (Kaguyahime series) is also being developed now.
Momotaro series
Sine wave drive for quiet sound and high efficiency.
Product feature
Sine Wave EnergizingCut the noise when the motor is energized |
A variety of speed adjustment methodsBuilt-in potentio-meter External potentio-meter |
 |
With one switchForward/Reverse |
Speed measurement, emergency alarmSpeed signal output Alarm signal Output |
|
Motor Destruction PreventionEquipped with motor overload protection function |
 |
 |
 |
VENUS series
Light・Small・Low cost
Product feature
So simple to useDirect speed control with knob |
Motor Quick brake/Various speed adjustment methodsBuilt-in Potentio Meter External Potentio Meter |
 |
With one switchForward/Reverse Start/Stop |
I want to measure the speed/alarm in an emergencySpeed signal output Alarm signal Output |
|
Don't let the motor break!Equipped with motor overload protection function |
|
|
|
Motor driver selection chart
| (mm) | (g) | （Vdc） | (Rated/Max.A) | ||||||
|---|---|---|---|---|---|---|---|---|---|
| Momotaro | Sine wave driver | MBLD250 | 97x101x28 | 200 | 10~50 | 7 / 10 | CPH40, CPH50 | Available |  |
| Large size sine wave energizing driver | MBLD500 | 119x143x71 | 964 | 10~50 | 25 / 28 | CPH62,CPH80E/F | Under development*1 | ||
| VENUS | Medium size coreless motor | MLD-030-ST | 96.5x143x38 | 450 | 24-48 | 12 / 16 | CPH62,CPH80E,CPHA50,CPH80E | Available | |
| Large size coreless motor | MLD-075-ST | 97x151x48 | 700 | 20-50 | 20 / 35 | CPH80F | Available | |
|
| Small size cored motor | MLD-012-S | 60x96x24.6 | 160 | 12-30 | 5 / 8 | Cored motor compatible | Built-to-order | ||
| Medium size cored motor | MLD-030-S | 96.5x143x38 | 450 | 24-48 | 12 / 16 | Cored motor compatible | Built-to-order | ||
| Large size cored motor | MLD-075-S | 97x151x48 | 700 | 20-50 | 20 / 35 | Cored motor compatible | Built-to-order | ||
| Kaguya | Low price Medium size AC servo driver |
TBD | TBD | TBD | 10-50 | Rated 15A | CPH40,CPH50, CPH62、CPH80E |
Under development*1 | |
| Low price Large size AC servo driver |
TBD | TBD | TBD | 10-50 | Rated 25A | CPH80F | Under development*1 |
*1 Model No. and specification of Under development are tentative. Please refer to officially announced specification. Availability status will be changed without notice.
*2 Because you may not be able to satisfy all the specifications of the motor, when selecting a driver, please carefully check specifications of the motor, specifications of the driver and your usage condition.
If you would like to consult our representative for the selection, please contact us directly or contact us in the website.
